32-Bit Arm ® Cortex ® -M0+ MCU
HT32F50231/HT32F50241
Port C Data Input Register – PCDINR
This register specifies the GPIO Port C input data.
Offset: 0x01C
Reset value: 0x0000_0000
31
Type/Reset
23
Type/Reset
15
Type/Reset
7
Type/Reset RO 0 RO
Bits Field
[7:0] PCDINn
Port C Output Data Register – PCDOUTR
This register specifies the GPIO Port C output data.
Offset: 0x020
Reset value: 0x0000_0000
31
Type/Reset
23
Type/Reset
15
Type/Reset
7
Type/Reset RW 0 RW
Bits Field
[7:0] PCDOUTn
Rev. 1.00
30 29 28
22 21 20
14 13 12
6 5 4
0 RO 0 RO
Descriptions
GPIO Port C pin n Data Input Bits (n = 0 ~ 7)
0: The input data of corresponding pin is 0
1: The input data of corresponding pin is 1
30 29 28
22 21 20
14 13 12
6 5 4
0 RW 0 RW
Descriptions
GPIO Port C pin n Data Output Bits (n = 0 ~ 7)
0: Data to be output on pin n is 0
1: Data to be output on pin n is 1
136 of 486
27 26
Reserved
19 18
Reserved
11 10
Reserved
3 2
PCDIN
0 RO 0 RO 0 RO
27 26
Reserved
19 18
Reserved
11 10
Reserved
3 2
PCDOUT
0 RW 0 RW 0 RW
25 24
17 16
9 8
1 0
0 RO 0
25 24
17 16
9 8
1 0
0 RW 0
July 31, 2018
