Register Map

The following table shows the PWM registers and reset values.

Table 31. PWM Register Map

Register
CNTCFR
MDCFR
TRCFR
CTR
CH0OCFR
CH1OCFR
CH2OCFR
CH3OCFR
CHCTR
CHPOLR
DICTR
EVGR
INTSR
CNTR
PSCR
CRR
CH0CR
CH1CR
CH2CR
CH3CR
CH0ACR
CH1ACR
CH2ACR
CH3ACR
Rev. 1.00
Offset
0x000 Timer Counter Configuration Register
0x004 Timer Mode Configuration Register
0x008 Timer Trigger Configuration Register
0x010 Timer Control Register
0x040 Channel 0 Output Configuration Register
0x044 Channel 1 Output Configuration Register
0x048 Channel 2 Output Configuration Register
0x04C Channel 3 Output Configuration Register
0x050 Channel Control Register
0x054 Channel Polarity Configuration Register
0x074 Timer Interrupt Control Register
0x078 Timer Event Generator Register
0x07C Timer Interrupt Status Register
0x080 Timer Counter Register
0x084 Timer Prescaler Register
0x088 Timer Counter Reload Register
0x090 Channel 0 Compare Register
0x094 Channel 1 Compare Register
0x098 Channel 2 Compare Register
0x09C Channel 3 Compare Register
0x0A0 Channel 0 Asymmetric Compare Register
0x0A4 Channel 1 Asymmetric Compare Register
0x0A8 Channel 2 Asymmetric Compare Register
0x0AC Channel 3 Asymmetric Compare Register
266 of 486
Description Reset Value
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_FFFF
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
