32-Bit Arm ® Cortex ® -M0+ MCU
HT32F50231/HT32F50241
Channel 1 Capture / Compare Register – CH1CCR
This register specifies the timer channel 1 capture / compare value.
Offset: 0x094
Reset value: 0x0000_0000
31
Type/Reset
23
Type/Reset
15
Type/Reset RW 0 RW
7
Type/Reset RW 0 RW
Bits Field
[15:0] CH1CCV
Rev. 1.00
30 29 28
22 21 20
14 13 12
0 RW 0 RW
6 5 4
0 RW 0 RW
Descriptions
Channel 1 Capture / Compare Value
- When Channel 1 is configured as an output
The CH1CCR value is compared with the counter value and the comparison result
is used to trigger the CH1OREF output signal.
- When Channel 1 is configured as an input
The CH1CCR register stores the counter value captured by the last channel 1
capture event.
242 of 486
27 26
Reserved
19 18
Reserved
11 10
CH1CCV
0 RW 0 RW 0 RW
3 2
CH1CCV
0 RW 0 RW 0 RW
25 24
17 16
9 8
0 RW 0
1 0
0 RW 0
July 31, 2018
