32-Bit Arm ® Cortex ® -M0+ MCU
HT32F50231/HT32F50241
Write Collision – WC
The following conditions will assert the Write Collision Flag.
▄
The FIFOEN bit in the SPIFCR register is cleared
The write collision flag is asserted when new data is written into the SPIDR register while both
the TX buffer and the shift register are already full. Any new data written into the TX buffer will
be lost.
▄
The FIFOEN bit in the SPIFCR register is set
The write collision flag is asserted to indicate that new data is written into the SPIDR register
while both the TX FIFO and the TX shift register are already full. Any new data written into the
TX FIFO will be lost.
Read Overrun – RO
▄
The FIFOEN bit in the SPIFCR register is cleared
The read overrun flag is asserted to indicate that both the RX shift register and the RX buffer are
already full, if one more data is received. This will result in the newly received data not being
shifted into the SPI shift register. As a result the latest received data will be lost.
▄
The FIFOEN bit in the SPIFCR register is set
The read overrun flag is set to indicate that the RX shift register and the RX FIFO are both full,
if one more data is received. This means that the latest received data can not be shifted into the
SPI shift register. As a result the latest received data will be lost.
Slave Abort – SA
In the SPI slave mode, the slave abort flag is set to indicate that the SEL pin suddenly changed to an
inactive state during the reception of a data frame transfer. The data frame length is set by the DFL
field in the SPICR1 register.

Register Map

The following table shows the SPI registers and their reset values.

Table 49. SPI Register Map

Register
SPICR0
SPICR1
SPIIER
SPICPR
SPIDR
SPISR
SPIFCR
SPIFSR
SPIFTOCR
Rev. 1.00
Offset
0x000 SPI Control Register 0
0x004 SPI Control Register 1
0x008 SPI Interrupt Enable Register
0x00C SPI Clock Prescaler Register
0x010 SPI Data Register
0x014 SPI Status Register
0x018 SPI FIFO Control Register
0x01C SPI FIFO Status Register
0x020 SPI FIFO Time Out Counter Register
428 of 486
Description Reset Value
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0003
0x0000_0000
0x0000_0000
0x0000_0000
