PIN CONNECTION
The illustration below shows how the heating-cable terminals on the AFM amplifier
correspond to the screw holes on the scanner holder tip.
TMPM5200-2
Heating-cable terminal
B+: Bias contact
B-: Bias reference contact
H+: Pin 1
H-: Pin 2
Pin 2
Bias electrode
Scanner
Pin 1
Bias reference contact
8 GENERAL
