５ MEASUREMENT OPERATION
4.
When the cantilever has moved 0.1 to 0.2 mm away from the specimen, click
on the Stop button to stop the movement.
5.
Turn the manual approach screw to move the specimen stage down.
The figure above shows the JSPM-5200.
5-142
SPM head unit
Groove
Cantilever holder
Manual approach screw
Stage moves upward
Stage moves downward
Tip holder
TMPM5200-2
