JEOL JSPM-5200 Instructions Manual page 111

５ MEASUREMENT OPERATION
c.
To deselect the 10
button
3.
C lick on the Lock-in button to open the Lock-in Amplifier window.
4.
Check the Enable check box to activate the lock-in amplifier.
5.
Specify the parameters according to the following table:
Sensitivity
Time Constant
Ref. Phase
6.
Click on the Advanced button.
The lock-in amplifier 1 Advanced window opens.
5-48
8
and 10
s into the popped-out state.
It will take about one second until the amplifier starts, initializing parameters.
If an error occurs, confirm connections and software settings.
10 mV
1 ms
0.000
6
buttons of the Input selection switches, put the
OSC Frequency
OSC Level
Output
40.000
1.000
ACosT, ASinT
TMPM5200-2
