8 GENERAL
Fine positioning
knob
Focusing knob
Locking knob
3.
Turn the zooming knob to set the magnification to the minimum.
4.
Adjust the fine positioning knob so that the cantilever comes to the center of
the image.
5.
Adjust the focusing knob so that correct focus is achieved on the cantilever.
6.
Turn the polarization filter knob so that you can see a high-quality image.
7.
Turn the zooming knob to obtain the desired magnification.
8-6
Zooming knob
Polarization filter knob
Top-view observation
bell jar (optional)
SPM head unit
Extension ring
(optional)
SPM base
TMPM5200-2
