3 CONFIGURAT ON AND DESCRIPTIONS OF COMPONENTS
I
3.3.1
SPM CONTROL System
The names and functions of each knob, button and terminal on the front and rear panels
of the SPM CONTROL system are shown below.
②
①
③
⑨
■ Front panel
① POWER button
This is the power switch of the SPM CONTROL system. When starting the instru-
ment, if this power switch is turned on before the computer power switch is turned
on, no reset operation is required.
3-14
POWER
⑧
⑤
④
ADB
CK
ADX
ADY
To AFM amp
FA-D
BS-D
MT
To SPM base
DT-D
Z120 SG
PR
To AFM
①
amp
To computer
Front panel
⑥
⑦
②
ADZ
CH2
LOCK
FA-A
To AFM amp
DT-A
⑩
To SPM base
Rear panel
F1T2A
AC100V/2A
To SPM base
TMPM5200-2
