７ APPENDIX
• Structure to record setting for profile and surface roughness analyses: ProfileDefType
wint_DialogControlSttsType
7-32
Type
POINTs [5] [2]
ｆloat [3] [2]
short
ｓhort [5]
ｓhort [3]
ｓhort [5]
POINTs [2]
POINTs [2]
COLORREF [5]
ｓhort [3]
ｂool
ｂool [5]
ｓhort [5]
CRect
short
short
short
POINTs [2]
bool
bool
ｂool [5]
short
short
ｓhort [5]
short
enum
ｃhar [49]
Size
40 bytes Coordinates of the line
24 bytes Location of the marker
2 bytes Dummy data
10 bytes Line indication
6 bytes Marker indication
10 bytes Active line
8 bytes Coordinates of Single Profile to be
recorded
8 bytes Coordinates of Multi Profile to be
recorded
20 bytes Color of each line
6 bytes Indication of marker to be recorded
1 byte Rz marker indicated/not indicated
5 bytes Broad Line setting
10 bytes Broad Line width
16 bytes Selected area for roughness analysis
2 bytes Setting of selected area for roughness
analysis
2 bytes Amount of movement by cursor （X）
2 bytes Amount of movement by cursor （Y）
8 bytes Coordinates of Extra Profile to be
recorded
1 byte Broad Line setting (Single Profile)
1 byte Ｂroad Line setting (Extra Profile)
5 bytes Broad Line setting (Multi Profile)
2 bytes Broad Line width (Single Profile)
2 bytes Broad Line width (Extra Profile)
10 bytes Broad Line width (Multi Profile)
Direction of Extra Profile（TRUE :
2 bytes
Vertical）
Application of "Rz On/Off" menu
2 bytes
Table 9）
（
49 bytes Buffer area
