Display Mode
Selection
Top View
Bird's Eye
Contour
Filled Contour
Overlaid
Contour
Number of Contours
The number of contour lines for the Contour mode is specified in this selection-box.
Nano Marker
A scale marker can be displayed to show the size of an image. When the X or Y check
box is checked, the marker is shown. The marker length and unit are automatically
calculated.
SPS Measurement Points
SPS Measurement Points on the displayed image can be displayed.
LUT Bar
The status for displaying images can be displayed.
If the check box is checked, the status for displaying images is that the LUT bar is
always displayed at the right of an image, and an image is always displayed as 400 × 400.
Text Overlay
Text and an arrow mark can be overlaid on the image in the Display Window.
Text frame
Selection
Justification frame
Selection
TMPM5200-2
This mode is the normal display mode. Height (signal level)
corresponds to brightness. Conversion of signal level to image
brightness is performed by LUT. Usually, a higher signal level
(height) is displayed at higher brightness.
An image is displayed as a shaded image.
Contour lines are displayed. Density of contour lines can be set in the
"No. of Contours" selection-box in this window.
Areas between the contour lines are filled with a brightness
corresponding to the image level.
Contour lines are overlaid onto the "Top View" image.
Off An arrow mark is displayed, but no text is overlaid.
Overlay Text is overlaid directly on the image.
Opaque Text is displayed on black background.
Left Text lines are left-justified.
Right Text lines are right-justified.
Center Text lines are centered.
