6.8.9

Replace Area

The black area made with the Extract Area operation is replaced by another image.
1.
After the Extract Area operation, click on Geometry in the main menu; then
select Replace Area in the pull-down menu.
Then a list of images stored in the computer memory is displayed on the window.
2.
Select an image to be inserted into the black area.
The black area of the current image is replaced by the selected image.
TMPM5200-2
2/2
1/2
Original image
Extract Area
Extract Area
Processed image

Replace Area

６ ANALYSIS OPERATION
Image list
Selection
6-69
