６ ANALYSIS OPERATION
6.8.5

Pad Points

The current image is shifted to the center of a larger frame.
The following three pads are provided:
Click on Geometry in the main menu; then select Pad Points in the pull-down
menu. Select 256 or 512 on the pull-down submenu. Then the current image
will be shifted to the center.
The surrounding area of the image is replaced by black (0).
6-66
512×512
128×128
Current image
128 × 128
256 × 256
512 × 512
Selecting any frame size other than those listed in the table above would cause
an error.
→ 256
→ 256
Padded image size
256, 512
512
―
Pad to 512
256×256
Black
