• Affixing a specimen for JSPM-5200/JSPM-5700
In order to observe a current image correctly, it is essential that good conductivity
be kept between the specimen and the specimen stub. Affix the specimen to the
specimen stub with conductive tape or conductive paste such as Conductive paste.
If possible, apply the conductive paste not only to the surface but to the side of the
specimen as well.
The
•
Selecting a cantilever
If there are two cantilevers, long an
want to use the short cantilever for image observation, be sure to remove the long
one using a pair of tweezers.
—— CAUTION ———————
TMPM5200-2
figure above shows the specimen for the JSPM-5200.
Long
cantilever
Tweezers
The top of the long cantilever
touches the specimen before
the short one.
When you select and
long and short, be sure to remove the long one with a pair of
tweezers. Otherwise, th
specimen before the short one does.
Specimen
Conductive paste
Specimen stub
d short, as shown in the figure below and you
Laser
Cantilever
use a short cantilever out of two cantilevers,
e top of the long cantilever touches the
５ MEASUREMENT OPERATION
5-117
