Repeat
Click ing on this button starts scanning in the mode specified in Acquisition. Scanning
repea ts continuously.
If yo u want to store the image,
that is being scanned will be stored in the computer memory.
Usually use Repeat for observing images.
When you perform SPS meas
FC measurement, set the number of scans once, using Single inste
prevent repeated collisions between the tip and the specimen.
Grab
Whe n you click on this button during s
wind ow, and the image data is stored in the computer memory when scanning is
comp lete. As Enter image title will be displayed at this moment, enter a title for the
imag e using the keyboard; then click on the OK button. This title is used only for data
stora ge in the memory and not for image saving on the disk. If you do not want to save
the image on the disk, click on the Cancel button. Then the image data is cleared.
A fter you click on the Grab button, scanning remains in suspension. To restart the scan,
cli ck on the Repeat button.
If you click on the Grab button during scanning, Cancel Grab will appear. If you click on
the button again, the grab command will be cancelled and return to Grab again. However,
scanning continues.
Single
When you click on this button, scanning is performed only once with the mode specified
in Acquisition, and the image is automatically grabbed in the computer memory. Use this
button to acquire data only once. It proves useful in cases such as Force Curve
measurement where repeated scanning might damage the specimen or the tip.
Grab & Repeat
Clicking on this button enables you to continuously measure up to 99 images, and to
automatically
You canno
SPS or SPS Mapping mode.
Since you can display the images measured by the Grab & Repeat function con
using the Play back function in the File menu when the observation object changes
time-sequentially, it is suitable to watch the object change.
When you scan the specimen using the Repeat function, specify the name and
destination for saving the file. A serial measurement number is automatically
attached to the filename. Refer to the procedure below.
In this measurement, the measured images are not recorded in memory. In order to
look at the measured images, you must read the saved image files from the disk.
The setting procedure is as follows:
1.
Click on the Grab & Repeat button.
A file operation dialog box appears.
2.
Select the folder in which you wish to save the measurement image (if
necessary, make a folder and select it), and then enter the filename.
TMPM5200-2
click on the Grab button during scanning. Then the data
save them in a file.
t perform continuous measurement in the 2 Inputs, 4 Inputs, Montage, Single
urement involving movement of the Z scanner such as
canning, Grab Frame appears in the SPM Status
５ MEASUREMENT OPERATION
ad of Repeat, to
tinuously
