JEOL JSPM-5200 Instructions Manual page 239

５ MEASUREMENT OPERATION
Stand ard Settings
The software returns the present setting values to the standard settings.
• St
andard settings for AC mode
Oscillation voltage
Oscillation Amplitude
Frequency shift direction
Start frequency
Stop frequency
• Standard settings for FMD mode
Oscillation voltage
Start frequency
Stop frequency
Selection of the AFM mode changes to AC.
■
Reset SPM
The SPM CONTROL unit is initialized by the signal from the software when the
WinSPM software starts up. Therefore, the power of the SPM CONTROL unit must be
turned on when the software starts up. You have to reset the SPM CONTROL unit using
the software
scanner or the SPM head, then have switched it on again.
Reset the SPM CONTROL unit according to the following procedure:
1.
Click on the SPM Setup menu from the main menu and select Reset SPM
from the pull-down menu.
The Reset SPM window appears.
2.
Confirm that the power supply of the SPM CONTROL unit is turned on, and
select the OK button.
5-176
whenever you have switched off the SPM CONTROL unit to replace the
0.01V
70%
Lower frequency
1 kHz
1000 kHz (1 MHz)
0.005 V
1 kHz
1000 kHz (1 MHz)
TMPM5200-2
