LOCATIONS OF PORTS
The illustration below shows the positional relationship of utility ports.
8.6
USER PORTS
The sizes of the extension rings correspond to those of the user ports here.
8-10
O ring (P5)
Screw (M4 × 8)
User port 2
O ring (P20)
Small port
Screw (M3 × 6)
User port 1
O ring (P12)
Flange
123
118
Large port
TMPM5200-2
