• Table 12 Display mode
■ CITS Image Header data structure
In the CITS image header data structure, CITS image data according to the number of
CITS images are successively recorded. When the number of CITS images is 128, the
size of the CITS image header file is given by:
CITS Image Header (165 bytes)×128 = 21,120 bytes.
unsigned short
wint_SourceType
■ CITS image data structure
The CITS image header is followed by information on a CITS image (current image at
each voltage) whose sequence is dependent on the CITS image header. When the number
of CITS images is 128, the size of the CITS image data file is as follows:
128 pixels×128 pixels×2 bytes×128 = 4,194,304 bytes.
■ Overall file size
The overall size of the CITS image file is
Normal Image Data (39,892 bytes) + CITS Header (390 bytes) +
CITS Image Header (21,120 bytes) + CITS Image Data (4,194,304 bytes)
= 4,255,706 bytes.
TMPM5200-2
0 normal
difference
1
normalize difference
2
normalized ADC
3
4 conductance
Type
short
short
unsigned char
short
int
float
float
float
char[40] 40 bytes
char[96] 96 bytes
• Table 13 Display mode
Size
2 bytes ADC minimum value
2 bytes ADC maximum value
1 byte ADC Source（not used）
2 bytes ADC Offset [mV]
2 bytes ADC Gain
4 bytes Head Amp Gain (1, 10, 100)
4 bytes Image Voltage
4 bytes Current at Image Data=0
4 bytes Current at Image Data=64
CITS image title
4 bytes Measurement signal（
Buffer
７ APPENDIX
0 none
spaced
1
first
2
last
3
4 mix up
Note
Table 8）
7-49
