７ APPENDIX
Address
0x02BC
0x02BE
0x02C6
0x02C7
0x02C8
0x02CC
0x02D0
0x02D2
0x02D4
0x02DE
0x02E8
0x02EC
0x02F0
:
0x031A
:
0x0356
0x035A
:
0x045E
:
0x04D4
:
:
:
0x07D4
0x07D8
0x07DC
0x07E0
0x07E4
0x07EC
7-24
Data Type
short
union ExtraType
char
char
struct CITSHeaderType*
float
short
short
unsigned char [10]
unsigned char [10]
float
float
CalibType
SPMParamType
MontageHeaderType*
char [260]
SPMParamType 1
unsigned char [3] [256]
long
enum ImageType 1
DataSourceType
DisplayModeType
FILETIMEUUnion
FILETIMEUUnion
Data Size
2 bytes Transform off
8 bytes Region selected from image
Image compressed or not
1 byte
(When compressed: TRUE)
1 byte Number of bits per pixel（0 = 8 bits）
Pointer to CITS data
4 bytes
(NULL if there is no data)
Tip voltage during back scan
4 bytes (Floating maximum value without
setting)
STS measurement point X (or -1,-1) in
2 bytes
the image
STS measurement point Y (or -1,-1) in
2 bytes
the image
10 bytes (^010)
10 bytes (^010)
Tip speed X [nm/s] during image
4 bytes
measurement
Tip speed Y [nm/s] during image
4 bytes
measurement
42 bytes Piezoelectric element sensitivity
60 bytes Detailed SPM parameters
Pointer to Montage data
4 bytes
(NULL if there is no data)
Image file location (full-path
260 bytes
specification)
118 bytes Miscellaneous SPM parameters
RBG Lookup Table
[0] [ ] : RED
768 bytes
[1] [ ] : GREEN
[2] [ ] : BLUE
4 bytes Sub Revision No.
4 bytes Kind of image（
4 bytes Kind of data source（
4 bytes Kind of indication（
8 bytes Measurement starting time
8 bytes Measurement ending time
Note
Table 1）
Table 2）
Table 3）
TMPM5200-2
