5.
Spec
6.
Click on the Advanced button.
The Lock-In-Amplifier 1 Advanced window opens.
7.
Specify the parameters according to the following table.
Filter
Filter Frequency/kHz
Line Reject
Track
Ref
2F
Slope/12dB
8.
Click on the Retract Off button in the Contact Mode tab window.
9.
Click on the Auto Configure button in the Lock-In-Amplifier window.
The lock-in amplifier will adjust the phase and gain automatically.
TMPM5200-2
It will take about one second until the Amplifier starts up
tion of parameters. If errors should happen, confirm connections and settings of
cables.
ify the parameters according to the following table.
Sensitivity 1 mV
Time Constant 1 ms
Ref. Phase 0.000
Band pass
20.000
Off
INT
□
□
５ MEASUREMENT OPERATION
due to the initializa-
OSC Frequency 20.000
OSC Level 0.200
Output ACosT, ASinT
Dynamic Res.
High Resolution
Offset
□
5-93
