⑥ Internal Trigger Source
Switches for selecting the trigger signal. These switches are in effect only when the
Trigger Source switch ⑤ is set to INT.
pressed) is used.
⑦ VARIABLE
A knob for varying the scanning rate continuously. Usually, push the knob and turn
it clockwise to the limit (the CAL position).
⑧ HOLD OFF
A knob for adjusting the holdoff time. Usually, turn it clockwise to the limit (the
NORM position).
⑨ LEVEL
A knob for setting the trigger level. Usually, turn it counterclockwise to the limit
(the FIX position).
TMPM5200-2
3 CONFIGURAT ON AND DESCRIPTIONS OF COMPONENTS
I
Usually, VERT (both switches are
3-19
