JEOL JSPM-5200 Instructions Manual page 224

2.
Shift the observ
The relationship between the actual observation field and the maximum observation
field is shown belo
■ Shifting observation field (Small shift)
If you wish to change the observation field within the range in which the measured
image is displayed, change the observation area using the following procedure.
Note that you cannot perform this operation in the basic mode.
1.
Click on the Drag button in the Scan frame of the SPM Parameters window.
When you move the cursor into the Display Window, it changes to the cursor shown
below.
2 .
Hold down the left mouse button and drag the Display Window.
The observation field will shift by e
To stop shifting the observation field, click on the right mouse button.
TMPM5200-2
ation field using the X and Y sliders or directly drag the field.
w.
Maximum observation field
Shift the observation field very slowly.
Shift the observation field very slowly.
Actual observation field
xactly the amount that you drag the cursor.
Observation
field shift
