６ ANALYSIS OPERATION
6.7.6
Particle Analysis
The Particle analysis function includes measurements of the number of particles and the
area of each particle in an image. The procedure for the particle analysis is shown below.
■ Particle Analyze Window
The particle analyze window and particle analyze setting window open when particle
analysis is conducted.
In the particle analyze window are displayed the image to analyze, binary digitized
image, image data and analysis result.
6-56
Binarizing of the image
Condition for particle
recognition
Is particle
analysis
possible ?
Analysis with other
software
TMPM5200-2
