6.3.2

Example of Using the Data Processing Function

The WinSPM system has more than 30 kinds of data processing functions.
The general flow of data processing is shown below.
■ Data Read
There are two methods of reading SPS data.
Transfer SPS data measured from the scan mode.
This method is useful for performing data processing while performing measurement.
1.
Using the scan mode, display the SPS data that you wish to analyze in the
Display Window.
2.
Click on Copy Data shortcut icon.
The displayed SPS data and the measured data are copied to the clipboard.
3.
Switch over the application to the process mode.
4.
Click on Paste Data shortcut icon
The SPS data and measurement data copied in the scan mode are transferred to the
process mode, and the image appears in the "Display Window".
Read an SPM image stored in a file.
Read the SPS data from the file.
1.
Click on Open shortcut icon.
The Open dialog box appears.
2.
Select the file that you wish to subject to image processing, and press the
Open (O) button.
The specified SPS data is loaded, and displayed in the Display Window.
TMPM5200-2
Evaluating the measured value
General data processing
The extension of an SPM image file is "spc".
Image read
Smoothing
Differentiation
End
