７ APPENDIX
Address
0x17EE
0x17FA
0x1806
0x1812
0x181E
7-36
Data Type
:
:
struct
12 bytes
:
TIFF_TAG
:
:
:
:
struct
12 bytes
:
TIFF_TAG
:
:
:
:
struct
:
12 bytes
TIFF_TAG
:
:
:
:
struct
12 bytes
:
TIFF_TAG
:
:
:
:
struct
12 bytes
:
TIFF_TAG
:
:
Size Data
02 01 TAG 258 "Bit Per Sample"
03 00 short type data
01 00 Data unit: 1
00 00 (TAG Data length = 2 bytes)
10 00 No. of bits per sample
"SPM Image" = 16 bits
00 00
03 01 TAG 259 "Compression"
03 00 short type data
01 00 Data unit: 1
(TAG Data length = 2 bytes)
00 00
01 00
Data compressed or not (1 = not
compressed)
00 00
TAG 262
06 01
"
Photometric interpretation
03 00 short type data
01 00 Data unit: 1
(TAG Data length = 2 bytes)
00 00
01 00 Gradation per pixel
（1 : 00→black FF→white）
00 00
0E 01 TAG 270 "Image Description"
02 00 ASCII data
No. of characters in internal
filename
20 08
Pointer to internal filename data
00 00
0F 01 TAG 271 "Make"
02 00 ASCII data
0B 00 Data unit: 11
(TAG Data length = 11 bytes)
00 00
Pointer to Make data
Note
"
TMPM5200-2
