4.
Specify 1 for the TOPO and F-force Gain boxes and then check the Autoset
check box (" ").
5.
Click on the Repeat button on the Advanced tab window.
Scanning starts and images are displayed on the Display Window as shown below.
The white locations in the FFM image represent areas of large friction force on the
specimen surface.
TMPM5200-2
Topography
FFM image
５ MEASUREMENT OPERATION
5-115
