After sixteen images are displayed in the Display Window, the displayed images are
updated with subsequent scanning in the order of ① → ② → ③...⑮ → ⑯ → ① → ②
→ ③ → .
• Mirror
Scanning is performed using 256 × 256 pixels. One image appears for left-to-right
movement, and a separate image appears for right-to-left movement. Scan starts
with the top line and proceeds to the bottom line. When the resulting scan is com-
plete, a new scan begins with the bottom line and proceeds to the top line.
When Mirror is selected, the bias voltage automatically changes between
left-to-right movement and right-to-left movement.
In the case of images displa
voltage specified in Bias is applied. In
side, the b
If the same voltage is specified for Bias and Back Scan, you can check each scan-
ning hysteresis and tip shape for left-to-right movement and for right-to-left move-
ment.
If a different voltage is specified for Bias and Back Scan in the STM mode, you can
observe STM images with two different bias voltages by one scanning.
• 2 Inputs (512
Two different kinds of data are acquired and displayed simultaneously. Scanning is
performed to acquire one image in 512 × 512 pixels. With com
pixels, the image appears during scanning. Specify source signals in the 1 and 2
boxe
Display Window.
5-204
ias voltage specified in Back Scan is applied.
)
s of the Display Source. Two images are displayed in the following order in the
① ② ③ ④
⑤ ⑥ ⑦ ⑧
⑨ ⑩ ⑪ ⑫
⑬ ⑭ ⑮ ⑯
yed on the left side in the Display
the case of the images displayed on the right
Window, the bias
pression to 256 × 256
