• Structure to record miscallaneous SPM parameters:
enum wint_VCOFMDynamicRangeType
7-30
Type
enum wint_SourceType
enum wint_SourceType
float
short
short
short
short
short
enum wint_AFMModeType
long
short
short
short
short
enum wint_activeDialogType
enum wint_SPMScanModeType
enum wint_SourceType
short
enum modeType
double
double
float
short
short
short
short
long
long
long
float
float
ｃhar [10]
SPM Param Type 1
Size Note
4 bytes Dummy data
4 bytes Dummy data
4 bytes DDS Frequency
2 bytes DDS Low Filter
2 bytes DDS High Filter
2 bytes DDS Center Filter
2 bytes DDS Enable
2 bytes Scan filter
4 bytes AFM mode （
4 bytes Slope gain
2 bytes X addition signal
2 bytes Y addition signal
2 bytes Z addition signal
2 bytes Bias addition signal
4 bytes Active Dialog （
4 bytes SPM Scan Mode （
Measurement signal （
4 bytes
8）
2 bytes Phase during VCO Scan
4 bytes SPS measurement mode
8 bytes DDS Amplitude
8 bytes DDS Center Locked Freq
4 bytes DDS Phase Shift
2 bytes DDS High Gain
2 bytes DDS Phase Polarity
2 bytes DDS PLL Excitation
2 bytes DDS External
4 bytes DDS RMS Filter
4 bytes DDS PLL Loop Gain
4 bytes DDS Beat Noise
4 bytes DDS Dynamic Range
4 bytes Cantilever Freq Peak
4 bytes Cantilever Q Factor
10
Buffer area
bytes
Table 5）
Table 6）
Table 7）
Table
