JEOL JSPM-5200 Instructions Manual page 271

５ MEASUREMENT OPERATION
Zoom
The area that you specify in the displayed image will be scann
This operation can change the scan size and scan area at the same time.
Click on the Zoom button; then move the cursor to the Display Window.
1.
e cursor will change to the + mark.
Th
2.
Specify a new scanning area by moving the curser from one point to another
diagonally, as shown below.
The new scanning area appears in the Size and Offset boxes.
You cannot carry out this operation during scanning. Stop scanning by clicking on
the Abort button; then specify a new scanning area.
Drag
You can shift the center point of the scanning area in the image to measure. This
operation is convenient when you wish to shift the field of view by a very small amount
during meas
1.
If you move the mouse
hold
shift by exactly the distance through which you dragged the mouse curser.
You can shift the field of view continuously by repeating this operation.
2.
To end this operation, click on the right mouse button.
The field of view shifts in real-time, so shift i
5-208
2/2
1/2
The cursor can move only on
the 45 ° lines.
urement.
ing down the left mouse button, the center point of the scanning area will
Zoom
curser in the Display Window while pressing and
Shifting field
of view
t slowly.
ed as a new scanning area.
The next scanning
TMPM5200-2
