７ APPENDIX
Address
0x1866
0x1872
0x187E
0x188A
0x1896
7-38
Data Type
:
:
struct
12 bytes
:
TIFF_TAG
:
:
:
:
ｓtruct
12 bytes
:
TIFF_TAG
:
:
:
:
struct
12 bytes
:
TIFF_TAG
:
:
:
:
struct
12 bytes
:
TIFF_TAG
:
:
:
:
struct
12 bytes
:
TIFF_TAG
:
:
Size Data
1A 01 TAG 282 "X Resolution"
05 00 Data type: rational
01 00 Data unit: 1
(TAG Data length = 8 bytes)
00 00
Pointer to X Resolution data
Resolution in the X direction
1B 01 TAG 283 "Y Resolution"
05 00 Rational type data
01 00 Data unit: 1
(TAG Data length = 8 bytes)
00 00
Pointer to Y Resolution data
Resolution in the Y direction
28 01 TAG 296 "Resolution Unit"
03 00 short type data
01 00 Data unit: 1
(TAG Data length = 2 bytes)
00 00
Resolution unit
3C 01 TAG 316 "Host Computer"
02 00 ASCII data
19 00 Data unit: 12
(TAG Data length = 12byte)
00 00
Pointer to Host Computer data
（"IBM Compatible(Windows) "）
00 00
00 00
00 00
No TAG data for SPM Image
00 00
00 00
00 00
Note
