JEOL JSPM-5200 Instructions Manual page 487

Address
0x18A2
0x18A6
0x1BD4
■ TIFF Image Data structure
The directory is followed by a file (TIFF image data area) containing the actual image
data. The amount of data per pixel is 16 bits (2 bytes). For instance, the size of the image
data file containing a 512×512 pixel image with 16 bits per pixel is 512 pixels×512
pixels×2 bytes = 524,288 bytes.
■ Overall file size
The size of the topographic image file is given by Header (10 bytes) + Image Header
(6,090 bytes) + Directory (1,024 bytes)
+ Image Data (524,288 bytes) = 531,412 bytes.
TMPM5200-2
Data Type
long
:
char [814]
:
:
:
:
Size Data
00 00 End of Directories
4 bytes
(NULL Pointer)
00 00
Buffer area
814
When the length of data excceds 4
bytes
bytes, TAG data is written here.
TIFF Image Data
:
７ APPENDIX
Note
7-39
