７ APPENDIX
• Structure to record 3-dimensional display settings:
7-34
Type
_3D_Mode
float [3]
float
float
float
float
float
float
float
float
float
float
float
short [2] [3]
float [2]
float [2]
float [2]
short [3]
short
short
short
LOGFONT
COLORREF
short
float
COLORREF
float
float
float
short [3]
char [246]
_3DsettingsType
Size
4 bytes 3-dimensional display mode（
10）
12 bytes XYZ rotation angles
4 bytes Z Scale
4 bytes Z Offset
4 bytes XYZ Scale
4 bytes X shift
4 bytes Y shift
4 bytes Perspective
4 bytes Mesh size X
4 bytes Mesh size Y
4 bytes Dispersion (Specular Level)
4 bytes Reflection (Diffuse Level)
4 bytes Brightness (Reflectivity)
12 bytes Surface display color (2 sheets)
8 bytes Light Azimuth
8 bytes Light Elevation
8 bytes Light Brightness
6 bytes XYZ scale display
2 bytes Side display
2 bytes Base display
2 bytes Light source display
60 bytes Scale indication font
4 bytes Scale indication color
2 bytes 3-dimensional display:
4 bytes XY Aspect ratio
4 bytes Background color
4 bytes Scale indication font size
4 bytes Title indication font size
4 bytes α value
6 bytes Indication of title scan size path
246 bytes Buffer area
Note
Table
TRUE
