５ MEASUREMENT OPERATION

■ Operation buttons

These are operation buttons concerning SPM measurement. They change depending on
the SPM mode or instrument model.
Sca n/Abort
Click on this button when you start measurement. When measurement starts, the
indication on the button changes to Abort. When you click on the button again un
condition, measurement stops.
Indication while measurement
This button appears gray while the tip is retracted.
If you stop measurement using this button, be careful th
recorded.
Grab/Canc el Grab
If you click on this button after starting measurement, the current measurement data is
recorded after completing th
reco rding state, the indication on the button changes to Cancel Grab. When you click
again under this state, the reserved recording is canceled (canceled reserved recording
state). In the canceled reserved recording
unle ss you stop the
This button appears gray while the measurement is not started.
This button also remains gray if the Auto record is not checked.
Auto Grab
While this checkbox is checked, the measurement data is recorded without fail after
measurement (always measure under the reserved recording state). Since it takes a fairly
long time to a
from forgetting to record the measurement data when you carry out measurement with
this check box checked.
When you want to measure continuously, as when searching the optimal values of the
measurement parameters or waiting until the creep and thermal drift ceases in the
scanner, carry out the measurement leaving this check box unchecked.
You cannot change the checkbox during measurement.
