11.3.4

IDMA Timing

From the host system interface point of view, there are three IDMA port
operations with critical timing parameters. These operations are:
• latching the IDMA internal memory address,
• reading from the IDMA port, and
• writing to the IDMA port.
The following sections cover the timing details of each of these operations.

11.3.4.1 Address Latch Cycle

The host writes the DMA starting address and destination memory type
(DM or PM) using the IDMA address latch cycle. The address latch cycle,
shown in Figure 11.9, consists of the following steps:
1. Host ensures that
2. Host asserts IAL and
starting address from the IAD15-0 address/data bus into the IDMA
Control Register.
3. Host drives the starting address (bits 0-13) and destination memory
type (bit 14) onto the IAD15-0 bus. (Bit 15 must be a 0.)
IRD
Note that and
operation.
IACK
IAL
IS
IAD15-0
Figure 11.9 IDMA Address Latch Cycle Timing
IACK
line is low.
IS
, directing the ADSP-2181 to latch the IDMA
IWR
remain high (inactive) throughout the latch
ADDRESS
DMA Ports 11
11 – 17
