The PowerPC Core

6.2 BASIC STRUCTURE OF THE CORE

To accomplish its tasks, the core is divided into the following subunits:
• Sequencer Unit—Consists of the branch processor (next address generation), the
instruction prefetch queue, and the interrupt handling mechanism. It controls some data
structures within the register unit.
• Register Unit—Consists of all the user-visible registers, the register's scoreboard
mechanism, and a history of previous operations to allow for a precise interrupt model.
This module is physically split so that each data structure is implemented near the area
in which it is used.
• Fixed-Point Unit—Implements all fixed-point instructions, except load/store
instructions. This module is subdivided into the following two blocks:
IMUL/IDIV–Fixed-point multiply and divide instruction implementation.
ALU/BFU–Fixed-point logic, add, and subtract instruction implementation, as well
as the bit field instructions.
• Load/Store Unit—Implements all load and store instructions. No floating-point
processor load and store instructions are implemented.

6.2.1 Instruction Flow Within the Core

When fetched, instructions enter the instruction queue and enable branch folding by
allowing out-of-order branch execution. Nonbranch instructions reaching the top of the
instruction queue are issued to the execution units. Instructions can be flushed from the
instruction queue in case of an exception on a previous instruction, interrupt, or
miss-predicted fetch.
All instructions, including branches, enter the history buffer along with processor state
information that can be affected by the instruction's execution. This information is used to
enable out-of-order completion of instructions together with precise exception handling.
When exceptions or interrupts occur, instructions can be flushed or recovered from the
machine. The instruction queue is always flushed when the history buffer is recovered. An
instruction retires from the machine after it finishes executing without exception and all
preceding instructions are retired from the machine. Figure 6-1 illustrates the core's
microarchitecture.
