Set Camera Parameter
Sets the value for the specified camera parameter.
Camera parameter numbers: p. 229
Command (PLC to Sensor)
First word of com-
mand area
12 to 15
+2
0001
+3
0000
+4
0000
+5
0000
+6
0000
+7
0000
Response (Sensor to PLC)
First word of
response area
12 to 15
+2
0001
+3
0000
+4
0000
+5
0000
FQ2-S/CH User's Manual
for Communications Settings
Bits
8 to 11
4 to 7
0 to 3
0000
0100
0000
0000
0101
0000
0000
0000
0000
0000
0000
0000
0000
0000
0000
0000
0000
0000
Bits
8 to 11
4 to 7
0 to 3
0000
0100
0000
0000
0101
0000
0000
0000
0000
0000
0000
0000
Description
Command code
Camera parameter number
Setting data
(1,000 times the value)
Description
Command code
The command code for which the response
applies is stored.
Response code
Command execution result
0: OK, FFFFFFFF: NG
249
Command Control
