General-purpose Timer Registers
13.5.1.18 TAR Register (Offset = 48h) [reset = FFFFFFFFh]
TAR is shown in Figure 13-26
Timer A Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10
Bit Field
31-0 TAR
1114
Timers
and described in Table
Figure 13-26. TAR Register
TAR
R-FFFFFFFFh
Table 13-25. TAR Register Field Descriptions
Type Reset Description
R FFFFFFFFh GPT Timer A Register
Based on the value in the register field TAMR.TAILD, this register is
updated with the value from TAILR register either on the next cycle
or on the next timeout.
A read returns the current value of the Timer A Count Register, in all
cases except for Input Edge count and Timer modes.
In the Input Edge Count Mode, this register contains the number of
edges that have occurred. In the Input Edge Time mode, this register
contains the time at which the last edge event took place.
Copyright © 2015, Texas Instruments Incorporated
13-25.
9 8
SWCU117C – February 2015 – Revised September 2015
www.ti.com
7 6 5 4 3 2 1 0
