General-purpose Timer Registers
13.5.1.1 CFG Register (Offset = 0h) [reset = 0h]
CFG is shown in Figure 13-9
Configuration
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10
Bit Field
31-3 RESERVED
2-0 CFG
1092
Timers
and described in Table
Figure 13-9. CFG Register
RESERVED
R-0h
Table 13-8. CFG Register Field Descriptions
Type Reset Description
R 0h
Software must not rely on the value of a reserved. Writing any other
value than the reset value may result in undefined behavior.
R/W 0h GPT Configuration
0x2- 0x3 - Reserved
0x5- 0x7 - Reserved
0h = 32BIT_TIMER : 32-bit timer configuration
1h = 32-bit real-time clock
4h = 16BIT_TIMER : 16-bit timer configuration.
Configure for two 16-bit timers.
Also see TAMR.TAMR and TBMR.TBMR.
Copyright © 2015, Texas Instruments Incorporated
13-8.
9 8
SWCU117C – February 2015 – Revised September 2015
www.ti.com
7 6 5 4 3 2 1 0
CFG
R/W-0h
