11.11.2.5 DOUT19_16 Register (Offset = 10h) [reset = 0h]
DOUT19_16 is shown in
Data Out 16 to 19
Alias register for byte access to each bit in DOUT31_0.
31 30
23 22
15 14
7 6
Bit Field
31-25 RESERVED
24 DIO19
23-17 RESERVED
16 DIO18
15-9 RESERVED
8 DIO17
7-1 RESERVED
0 DIO16
SWCU117C – February 2015 – Revised September 2015
Submit Documentation Feedback
Figure 11-12 and described in
Figure 11-12. DOUT19_16 Register
29 28
RESERVED
R-0h
21 20
RESERVED
R-0h
13 12
RESERVED
R-0h
5 4
RESERVED
R-0h
Table 11-15. DOUT19_16 Register Field Descriptions
Type Reset
R 0h
W 0h
R 0h
W 0h
R 0h
W 0h
R 0h
W 0h
Copyright © 2015, Texas Instruments Incorporated
Table 11-15.
27 26
19 18
11 10
3 2
Description
Software must not rely on the value of a reserved. Writing any other
value than the reset value may result in undefined behavior.
Sets the state of the pin that is configured as DIO 19, if the
corresponding DOE31_0 bit field is set.
Software must not rely on the value of a reserved. Writing any other
value than the reset value may result in undefined behavior.
Sets the state of the pin that is configured as DIO 18, if the
corresponding DOE31_0 bit field is set.
Software must not rely on the value of a reserved. Writing any other
value than the reset value may result in undefined behavior.
Sets the state of the pin that is configured as DIO 17, if the
corresponding DOE31_0 bit field is set.
Software must not rely on the value of a reserved. Writing any other
value than the reset value may result in undefined behavior.
Sets the state of the pin that is configured as DIO 16, if the
corresponding DOE31_0 bit field is set.
I/O Control Registers
25 24
DIO19
W-0h
17 16
DIO18
W-0h
9 8
DIO17
W-0h
1 0
DIO16
W-0h
