Texas Instruments SimpleLink CC2620 Technical Reference Manual page 858

Cryptography Registers
10.2.1.27 AESDATAOUT2 Register (Offset = 568h) [reset = 0h]
AESDATAOUT2 is shown in
AES Data Input/Output 2
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10
Bit Field
31-0 DATA
858
Figure 10-29 and described in
Figure 10-29. AESDATAOUT2 Register
DATA
R-0h
Table 10-37. AESDATAOUT2 Register Field Descriptions
Type Reset
R 0h
Copyright © 2015, Texas Instruments Incorporated
Table 10-37.
9
Description
Data registers for output block data from the Crypto peripheral.
These bits = AES Output Data[95:64] of [127:0]
For normal operations, this register is not used because data input
and output is transferred from and to the AES engine through DMA.
For a Host read operation, these registers contain the 128-bit output
block from the latest AES operation. Reading from a word-aligned
offset within this address range will read one word (4 bytes) of data
out the 4-word deep (16 bytes = 128-bits AES block) data output
buffer. The words (4 words, one full block) must be read before the
core will move the next block to the data output buffer. To empty the
data output buffer, AESCTL.OUTPUT_RDY must be written.
For the modes with authentication (CBC-MAC, GCM and CCM), the
invalid (message) bytes/words can be written with any data.
Note: The AAD / authentication only data is not copied to the output
buffer but only used for authentication.
SWCU117C – February 2015 – Revised September 2015
www.ti.com
8 7 6 5 4 3 2 1
