Radio Registers
23.8.1.7 RATCH5VAL Register (Offset = 94h) [reset = 0h]
RATCH5VAL is shown in
Timer Channel 5 Capture/Compare Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10
Bit Field
31-0 VAL
1606
Radio
Figure 23-18 and described in
Figure 23-18. RATCH5VAL Register
VAL
R/W-0h
Table 23-161. RATCH5VAL Register Field Descriptions
Type Reset
R/W 0h
Copyright © 2015, Texas Instruments Incorporated
Table 23-161.
9
Description
Capture/compare value. The system CPU can safely read this
register, but it is recommended to use the CPE API commands to
configure it for compare mode.
