Texas Instruments SimpleLink CC2620 Technical Reference Manual page 1108

General-purpose Timer Registers
13.5.1.12 TAMATCHR Register (Offset = 30h) [reset = FFFFFFFFh]
TAMATCHR is shown in
Timer A Match Register
Interrupts can be generated when the timer value is equal to the value in this register in one-shot or
periodic mode.
In Edge-Count mode, this register along with TAILR, determines how many edge events are counted.
The total number of edge events counted is equal to the value in TAILR minus this value.
Note that in edge-count mode, when executing an up-count, the value of TAPR and TAILR must be
greater than the value of TAPMR and TAMATCHR.
In PWM mode, this value along with TAILR, determines the duty cycle of the output PWM signal.
When a 16/32-bit GPT is configured to one of the 32-bit modes, TAMATCHR appears as a 32-bit register.
(The upper 16-bits correspond to the contents TBMATCHR).
In a 16-bit mode, the upper 16 bits of this register read as 0s and have no effect on the state of
TBMATCHR.
Note : This register is updated internally (takes effect) based on TAMR.TAMRSU
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10
Bit Field
31-0 TAMATCHR
1108
Timers
Figure 13-20 and described in
Figure 13-20. TAMATCHR Register
TAMATCHR
R/W-FFFFFFFFh
Table 13-19. TAMATCHR Register Field Descriptions
Type Reset
R/W FFFFFFFFh GPT Timer A Match Register
Copyright © 2015, Texas Instruments Incorporated
Table 13-19.
9
Description
SWCU117C – February 2015 – Revised September 2015
www.ti.com
8 7 6 5 4 3 2 1
Submit Documentation Feedback
0
