General-purpose Timer Registers
13.5.1.8 MIS Register (Offset = 20h) [reset = 0h]
MIS is shown in Figure 13-16
Masked Interrupt Status
Values are result of bitwise AND operation between RIS and IMR
Assosciated clear register: ICLR
31 30
23 22
15 14
RESERVED
R-0h
7 6
RESERVED
R-0h
Bit Field
31-17 RESERVED
16 WUMIS
15-14 RESERVED
13 DMABMIS
12 RESERVED
11 TBMMIS
10 CBEMIS
9 CBMMIS
8 TBTOMIS
7-6 RESERVED
5 DMAAMIS
4 TAMMIS
3 RTCMIS
2 CAEMIS
1 CAMMIS
0 TATOMIS
1104
Timers
and described in Table
Figure 13-16. MIS Register
29 28
RESERVED
R-0h
21 20
RESERVED
R-0h
13 12
DMABMIS RESERVED
R-0h R-0h
5 4
DMAAMIS TAMMIS
R-0h R-0h
Table 13-15. MIS Register Field Descriptions
Type Reset
R 0h
R 0h
R 0h
R 0h
R 0h
R 0h
R 0h
R 0h
R 0h
R 0h
R 0h
R 0h
R 0h
R 0h
R 0h
R 0h
Copyright © 2015, Texas Instruments Incorporated
13-15.
27 26
19 18
11 10
TBMMIS CBEMIS
R-0h R-0h
3 2
RTCMIS CAEMIS
R-0h R-0h
Description
Software must not rely on the value of a reserved. Writing any other
value than the reset value may result in undefined behavior.
0: No interrupt or interrupt not enabled
1: RIS.WURIS = 1 && IMR.WUMIS = 1
Software must not rely on the value of a reserved. Writing any other
value than the reset value may result in undefined behavior.
0: No interrupt or interrupt not enabled
1: RIS.DMABRIS = 1 && IMR.DMABIM = 1
Software must not rely on the value of a reserved. Writing any other
value than the reset value may result in undefined behavior.
0: No interrupt or interrupt not enabled
1: RIS.TBMRIS = 1 && IMR.TBMIM = 1
0: No interrupt or interrupt not enabled
1: RIS.CBERIS = 1 && IMR.CBEIM = 1
0: No interrupt or interrupt not enabled
1: RIS.CBMRIS = 1 && IMR.CBMIM = 1
0: No interrupt or interrupt not enabled
1: RIS.TBTORIS = 1 && IMR.TBTOIM = 1
Software must not rely on the value of a reserved. Writing any other
value than the reset value may result in undefined behavior.
0: No interrupt or interrupt not enabled
1: RIS.DMAARIS = 1 && IMR.DMAAIM = 1
0: No interrupt or interrupt not enabled
1: RIS.TAMRIS = 1 && IMR.TAMIM = 1
0: No interrupt or interrupt not enabled
1: RIS.RTCRIS = 1 && IMR.RTCIM = 1
0: No interrupt or interrupt not enabled
1: RIS.CAERIS = 1 && IMR.CAEIM = 1
0: No interrupt or interrupt not enabled
1: RIS.CAMRIS = 1 && IMR.CAMIM = 1
0: No interrupt or interrupt not enabled
1: RIS.TATORIS = 1 && IMR.TATOIM = 1
SWCU117C – February 2015 – Revised September 2015
www.ti.com
25 24
17 16
WUMIS
R-0h
9 8
CBMMIS TBTOMIS
R-0h R-0h
1 0
CAMMIS TATOMIS
R-0h R-0h
