I/O Control Registers
11.11.2.6 DOUT23_20 Register (Offset = 14h) [reset = 0h]
DOUT23_20 is shown in
Data Out 20 to 23
Alias register for byte access to each bit in DOUT31_0.
31 30
23 22
15 14
7 6
Bit Field
31-25 RESERVED
24 DIO23
23-17 RESERVED
16 DIO22
15-9 RESERVED
8 DIO21
7-1 RESERVED
0 DIO20
892
I/O Control
Figure 11-13 and described in
Figure 11-13. DOUT23_20 Register
29 28
RESERVED
R-0h
21 20
RESERVED
R-0h
13 12
RESERVED
R-0h
5 4
RESERVED
R-0h
Table 11-16. DOUT23_20 Register Field Descriptions
Type Reset
R 0h
W 0h
R 0h
W 0h
R 0h
W 0h
R 0h
W 0h
Copyright © 2015, Texas Instruments Incorporated
Table 11-16.
27 26
19 18
11 10
3 2
Description
Software must not rely on the value of a reserved. Writing any other
value than the reset value may result in undefined behavior.
Sets the state of the pin that is configured as DIO 23, if the
corresponding DOE31_0 bit field is set.
Software must not rely on the value of a reserved. Writing any other
value than the reset value may result in undefined behavior.
Sets the state of the pin that is configured as DIO 22, if the
corresponding DOE31_0 bit field is set.
Software must not rely on the value of a reserved. Writing any other
value than the reset value may result in undefined behavior.
Sets the state of the pin that is configured as DIO 21, if the
corresponding DOE31_0 bit field is set.
Software must not rely on the value of a reserved. Writing any other
value than the reset value may result in undefined behavior.
Sets the state of the pin that is configured as DIO 20, if the
corresponding DOE31_0 bit field is set.
SWCU117C – February 2015 – Revised September 2015
www.ti.com
25 24
DIO23
W-0h
17 16
DIO22
W-0h
9 8
DIO21
W-0h
1 0
DIO20
W-0h
