11.11.2.9 DOUT31_0 Register (Offset = 80h) [reset = 0h]
DOUT31_0 is shown in
Data Output for DIO 0 to 31
31 30
DIO31 DIO30
R/W-0h R/W-0h
23 22
DIO23 DIO22
R/W-0h R/W-0h
15 14
DIO15 DIO14
R/W-0h R/W-0h
7 6
DIO7 DIO6
R/W-0h R/W-0h
Bit Field
31 DIO31
30 DIO30
29 DIO29
28 DIO28
27 DIO27
26 DIO26
25 DIO25
24 DIO24
23 DIO23
22 DIO22
21 DIO21
20 DIO20
19 DIO19
18 DIO18
17 DIO17
16 DIO16
15 DIO15
14 DIO14
13 DIO13
12 DIO12
11 DIO11
10 DIO10
9 DIO9
8 DIO8
7 DIO7
SWCU117C – February 2015 – Revised September 2015
Submit Documentation Feedback
Figure 11-16 and described in
Figure 11-16. DOUT31_0 Register
29 28
DIO29 DIO28
R/W-0h R/W-0h
21 20
DIO21 DIO20
R/W-0h R/W-0h
13 12
DIO13 DIO12
R/W-0h R/W-0h
5 4
DIO5 DIO4
R/W-0h R/W-0h
Table 11-19. DOUT31_0 Register Field Descriptions
Type Reset
R/W 0h
R/W 0h
R/W 0h
R/W 0h
R/W 0h
R/W 0h
R/W 0h
R/W 0h
R/W 0h
R/W 0h
R/W 0h
R/W 0h
R/W 0h
R/W 0h
R/W 0h
R/W 0h
R/W 0h
R/W 0h
R/W 0h
R/W 0h
R/W 0h
R/W 0h
R/W 0h
R/W 0h
R/W 0h
Copyright © 2015, Texas Instruments Incorporated
Table 11-19.
27 26
DIO27 DIO26
R/W-0h R/W-0h
19 18
DIO19 DIO18
R/W-0h R/W-0h
11 10
DIO11 DIO10
R/W-0h R/W-0h
3 2
DIO3 DIO2
R/W-0h R/W-0h
Description
Data output for DIO 31
Data output for DIO 30
Data output for DIO 29
Data output for DIO 28
Data output for DIO 27
Data output for DIO 26
Data output for DIO 25
Data output for DIO 24
Data output for DIO 23
Data output for DIO 22
Data output for DIO 21
Data output for DIO 20
Data output for DIO 19
Data output for DIO 18
Data output for DIO 17
Data output for DIO 16
Data output for DIO 15
Data output for DIO 14
Data output for DIO 13
Data output for DIO 12
Data output for DIO 11
Data output for DIO 10
Data output for DIO 9
Data output for DIO 8
Data output for DIO 7
