Texas Instruments SimpleLink CC2620 Technical Reference Manual page 932

I/O Control Registers
Table 11-32. IOCFG5 Register Field Descriptions (continued)
Bit Field
5-0 PORT_ID
932
I/O Control
Type Reset Description
R/W 0h
Selects usage for DIO5
0h = General Purpose IO
7h = AON 32-kHz clock (SCLK_LF)
8h = AUX IO
9h = SSI0_RX : SSI0 RX
Ah = SSI0_TX : SSI0 TX
Bh = SSI0_FSS : SSI0 FSS
Ch = SSI0_CLK : SSI0 CLK
Dh = I2C_MSSDA : I2C Data
Eh = I2C_MSSCL : I2C Clock
Fh = UART0_RX : UART0 RX
10h = UART0_TX : UART0 TX
11h = UART0_CTS : UART0 CTS
12h = UART0_RTS : UART0 RTS
17h = PORT_EVENT0 : PORT EVENT 0
Can be used as a general purpose IO event by selecting it through
registers in the EVENT module, for example,
EVENT:GPT0ACAPTSEL.EV, EVENT:UDMACH14BSEL.EV, and so
on.
18h = PORT_EVENT1 : PORT EVENT 1
Can be used as a general purpose IO event by selecting it through
registers in the EVENT module, for example,
EVENT:GPT0ACAPTSEL.EV, EVENT:UDMACH14BSEL.EV, and so
on.
19h = PORT_EVENT2 : PORT EVENT 2
Can be used as a general purpose IO event by selecting it through
registers in the EVENT module, for example,
EVENT:GPT0ACAPTSEL.EV, EVENT:UDMACH14BSEL.EV, and so
on.
1Ah = PORT_EVENT3 : PORT EVENT 3
Can be used as a general purpose IO event by selecting it through
registers in the EVENT module, for example,
EVENT:GPT0ACAPTSEL.EV, EVENT:UDMACH14BSEL.EV, and so
on.
1Bh = PORT_EVENT4 : PORT EVENT 4
Can be used as a general purpose IO event by selecting it through
registers in the EVENT module, for example,
EVENT:GPT0ACAPTSEL.EV, EVENT:UDMACH14BSEL.EV, and so
on.
1Ch = PORT_EVENT5 : PORT EVENT 5
Can be used as a general purpose IO event by selecting it through
registers in the EVENT module, for example,
EVENT:GPT0ACAPTSEL.EV, EVENT:UDMACH14BSEL.EV, and so
on.
1Dh = PORT_EVENT6 : PORT EVENT 6
Can be used as a general purpose IO event by selecting it through
registers in the EVENT module, for example,
EVENT:GPT0ACAPTSEL.EV, EVENT:UDMACH14BSEL.EV, and so
on.
1Eh = PORT_EVENT7 : PORT EVENT 7
Can be used as a general purpose IO event by selecting it through
registers in the EVENT module, for example,
EVENT:GPT0ACAPTSEL.EV, EVENT:UDMACH14BSEL.EV, and so
on.
20h = CPU_SWV : CPU SWV
21h = SSI1_RX : SSI1 RX
22h = SSI1_TX : SSI1 TX
23h = SSI1_FSS : SSI1 FSS
24h = SSI1_CLK : SSI1 CLK
