11.11.2.3 DOUT11_8 Register (Offset = 8h) [reset = 0h]
DOUT11_8 is shown in
Data Out 8 to 11
Alias register for byte access to each bit in DOUT31_0.
31 30
23 22
15 14
7 6
Bit Field
31-25 RESERVED
24 DIO11
23-17 RESERVED
16 DIO10
15-9 RESERVED
8 DIO9
7-1 RESERVED
0 DIO8
SWCU117C – February 2015 – Revised September 2015
Submit Documentation Feedback
Figure 11-10 and described in
Figure 11-10. DOUT11_8 Register
29 28
RESERVED
R-0h
21 20
RESERVED
R-0h
13 12
RESERVED
R-0h
5 4
RESERVED
R-0h
Table 11-13. DOUT11_8 Register Field Descriptions
Type Reset
R 0h
W 0h
R 0h
W 0h
R 0h
W 0h
R 0h
W 0h
Copyright © 2015, Texas Instruments Incorporated
Table 11-13.
27 26
19 18
11 10
3 2
Description
Software must not rely on the value of a reserved. Writing any other
value than the reset value may result in undefined behavior.
Sets the state of the pin that is configured as DIO 11, if the
corresponding DOE31_0 bit field is set.
Software must not rely on the value of a reserved. Writing any other
value than the reset value may result in undefined behavior.
Sets the state of the pin that is configured as DIO 10, if the
corresponding DOE31_0 bit field is set.
Software must not rely on the value of a reserved. Writing any other
value than the reset value may result in undefined behavior.
Sets the state of the pin that is configured as DIO 9, if the
corresponding DOE31_0 bit field is set.
Software must not rely on the value of a reserved. Writing any other
value than the reset value may result in undefined behavior.
Sets the state of the pin that is configured as DIO 8, if the
corresponding DOE31_0 bit field is set.
I/O Control Registers
25 24
DIO11
W-0h
17 16
DIO10
W-0h
9 8
DIO9
W-0h
1 0
DIO8
W-0h
