10.2.1.40 HWVER Register (Offset = 7FCh) [reset = 91118778h]
HWVER is shown in
CTRL Module Version
31 30 29 28
RESERVED
R-9h
15 14 13 12
VER_NUM_COMPL
Bit Field
31-28 RESERVED
27-24 HW_MAJOR_VER
23-20 HW_MINOR_VER
19-16 HW_PATCH_LVL
15-8 VER_NUM_COMPL
7-0 VER_NUM
SWCU117C – February 2015 – Revised September 2015
Submit Documentation Feedback
Figure 10-42 and described in
Figure 10-42. HWVER Register
27 26 25
HW_MAJOR_VER
R-1h
11 10 9
R-87h
Table 10-50. HWVER Register Field Descriptions
Type Reset
R 9h
R 1h
R 1h
R 1h
R 87h
R 78h
Copyright © 2015, Texas Instruments Incorporated
Table 10-50.
24 23 22 21
HW_MINOR_VER
R-1h
8 7 6 5
Description
Software must not rely on the value of a reserved. Writing any other
value than the reset value may result in undefined behavior.
Major version number
Minor version number
Patch level, starts at 0 at first delivery of this version.
These bits simply contain the complement of VER_NUM (0x87),
used by a driver to ascertain that the Crypto peripheral register is
indeed read.
The version number for the Crypto peripheral, this field contains the
value 120 (decimal) or 0x78.
Cryptography Registers
20 19 18 17
HW_PATCH_LVL
R-1h
4 3 2 1
VER_NUM
R-78h
16
0
