RF Core HAL
23.3.4.15 CMD_DISARM_RAT_CH: Disarm RAT Channel
Command ID number: 0x040A
CMD_DISARM_RAT_CH is an immediate command that takes the parameters listed in
Byte Index Field Name
0–1 commandNo
2 ratCh
On reception, the radio CPU disarms the RAT channel given by ratCh.
CMD_DISABLE_RAT_CH may be sent as a direct command. If so, ratCh is given by the parameter in bits
8–15 of CMDR.
The channel number must indicate a channel not reserved for use by the radio CPU. Otherwise, the radio
CPU returns ParError in CMDSTA. If the channel number is valid, the CPU returns Done in CMDSTA after
the channel has been armed.
1510
Radio
Table 23-46. CMD_DISARM_RAT_CH Command Format
Bits Bit Field Name
Copyright © 2015, Texas Instruments Incorporated
Type Description
W The command ID number
W The radio timer channel number
SWCU117C – February 2015 – Revised September 2015
www.ti.com
Table 23-46.
