10.2.1.17 AESKEY3_0 to AESKEY3_3 Register (Offset = 510h to 51Ch) [reset = 0h]
AESKEY3_0 to AESKEY3_3 is shown in
Clear AES_KEY3
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10
Table 10-27. AESKEY3_0 to AESKEY3_3 Register Field Descriptions
Bit Field
31-0 KEY3
SWCU117C – February 2015 – Revised September 2015
Submit Documentation Feedback
Figure 10-19
Figure 10-19. AESKEY3_0 to AESKEY3_3 Register
KEY3
W-0h
Type Reset Description
W 0h AESKEY3.* bits 31+x:0+x or AESKEY2.* bits 159+x:128+x, where x
= 0, 32, 64, 96 ordered from the LSW entry of this 4-deep register
arrary.
The interpretation of this field depends on the crypto operation
mode.
Copyright © 2015, Texas Instruments Incorporated
and described in Table 10-27.
9 8 7
Cryptography Registers
6 5 4 3 2 1 0
